Brewer Spectrophotometer Calibration

Calibration of Instrument Constants

Calibration of Instrument Constants Used in Total Ozone Observations
In Brewer spectrophotometer-based measurement of total ozone, the absorption coefficient and extraterrestrial constant are required as instrument parameters. The absorption coefficient is calibrated using multiple emission lines from spectral lamps (zinc, cadmium, and mercury). Once this value is determined, intercomparison observations using sunlight are conducted with a reference instrument, and the extraterrestrial constant is calibrated based on the results. The Japan Meteorological Agency (JMA)’s domestic reference instrument maintains observational accuracy for this purpose by regularly conducting intercomparison observations with the WMO’s world reference triad managed by Environment and Climate Change Canada (ECCC). The extraterrestrial constant for instruments used at individual observation stations is also maintained through intercomparison with the domestic reference instrument.
Calibration of Instrument Constants Used in Spectral UV Observations
In Brewer spectrophotometer-based measurement of spectral UV, dispersion and sensitivity constants are required as instrument parameters. The dispersion constant is calibrated using multiple emission lines from spectral lamps (zinc, cadmium, and mercury), while the sensitivity constant is calibrated using a 1,000 W tungsten-halogen lamp with illuminance calibrated by the U.S. National Institute of Standards and Technology (NIST). To maintain observational accuracy, JMA regularly conducts intercomparison observations using sunlight with ECCC’s world reference triad to verify the observational integrity of the Japanese standard. The dispersion and sensitivity constants for instruments used at individual observatories are also calibrated using these lamps, and related observational accuracy is verified through regular intercomparison observations using sunlight with the Japanese standard. For instruments in operation, changes in illuminance are also recorded through periodic inspections using external standard lamps, and observation values are corrected based on the results.
Photo of Brewer spectrophotometer between the JMA’s domestic reference and the WMO’s world reference triad.

Intercomparison of Brewer spectrophotometer between the JMA’s domestic reference and the WMO’s world reference triad.

Maintenance and Management

To ensure measurement accuracy and instrument stability, JMA performs regular maintenance and inspections for individual instruments. In this process, drive mechanisms are cleaned and greased, and parts are replaced as necessary. Following maintenance, calibration is performed for total ozone and spectral UV observations.
